PCB NTAG 213 NFC Tag

Are you looking for a reliable supplier who can provide cost-effective PCB NTAG213 NFC tags? We are what you are looking for.

The PCB NTAG 213 NFC Tag (printed circuit board) antenna is suitable for the design of customized tags including special requests for shape (e.g. square shape). The PCB NTAG 213 NFC Tag can be easily fitted with an additional capacitor, which increases the reading distance of the tag.

We can offer customized services of PCB NFC tag and the factory price will be bound to meet you.

\ PCB NTAG 213 NFC Tag Descriptions

PCB NTAG 213 NFC Tag has the characteristics of high-temperature resistance, pressure resistance, and small size, etc. In the process of injection molding, due to its high-temperature resistance, the NFC chip will not be damaged by the Injection temperature,so it is ideal for integration into a variety of electronic devices,for Bluetooth pairing and information interaction with mobile phones.



Additionally,  compared with NTAG 203 chip, NTAG 213 chip has a better RF performance and higher safety performance to prevent the tag from being dismantled or counterfeited. You can give each product with a PCB NTAG213 NFC tag to effectively prevent fake products from impacting the market.



Other features of NTAG213 chip:



● Manufacturer programmed 7-byte UID for each device

● Pre-programmed Capability container with one time programmable bits

● Field programmable read-only locking function

● ECC based originality signature

● 32-bit password protection to prevent unauthorized memory operations

● Contactless transmission of data and supply energy

● Configurable password protection with optional limit of unsuccessful attempts

● Anti-tearing support for capability container (CC) and lock bits

● ECC supported originality check

● 7-byte serial number (cascade level 2 according to ISO/IEC 14443-3)

● UID ASCII mirror for automatic serialization of NDEF messages

● Automatic NFC counter triggered at read command

● NFC counter ASCII mirror for automatic adding the NFC counter value to the NDEF message

● Fast read command

● True anticollision



2\ PCB NTAG 213 NFC Tag Applications

1、Applications with clear requirements for circuit stability, abrasion and corrosion resistance, such as pipeline production data inventory management under the high-temperature environment, inventory control of incoming and outgoing items, and inventory control of injection-molded plastic parts.



2、Applications where modules need to be assembled or repackaged, such as Bluetooth speaker, Bluetooth headset or used to encapsulate special purpose labels like laundry labels, silicone wristbands, etc.



3\ PCB NTAG 213 NFC Tag Technical Specifications

Parameters
Material PCB
Chip NTAG 213
Frequency 13.56KHz
Protocol ISO14443A
Size Ø 10mm,Ø 15mm,Ø 16mm,Ø 17mm,Ø 18mm,Ø 20mm,Ø 25mm,16*16mm,18*18mm,
14*8mm,12*18mm,18*25mm,12*18mm,18*25mm,12*18mm,10*25mm,12*22mm,etc.
Thickness 0.08mm-3.0mm
Operating Distance up to 100 mm (depending on various parameters as e.g. field strength and antenna geometry)
Write Endurance 100000 times
Data Transfer 106 kbit/s
Input Capacitance 50 pF
Temperature -30℃ to + 250℃
Data Retention Time 10 years
Crafts Available Printed LOGO or Serial number
Shipping Details Generally, 3 days for DHL/FedEx/UPS, 10 days for air shipping,18 days for sea shipping.



4\ PCB NTAG 213 NFC Tag Customized Service

We can provide customized services. You can choose the appropriate frequency, chip, and antenna according to your application environment. Different combinations can achieve different functions. You can also tell us the size, shape and color you want, and we can make it according to your requirements.


Common Chip Types Protocol Capacity Anti-collision Function
Available 125KHz Chip
TK4100 / 64 bit No Read Only
EM4200 / 128 bit No Read Only
EM4305 / 512 bit No Read/Write
T5577 / 330 bits No Read/Write
Available 13.56MHz Chip
NTAG 213 ISO14443A 180 byte No Read/Write
NTAG 215 ISO14443A 540 byte No Read/Write
NTAG 216 ISO14443A 924 byte No Read/Write
MIFARE Classic 1K ISO14443A 1 KB No Read/Write
MIFARE Classic 4K ISO14443A 4 KB No Read/Write
MIFARE Plus S 1K ISO14443A 2 KB/4 KB No Read/Write
MIFARE Ultralight EV1 ISO14443A 80 byte No Read/Write
MIFARE Ultralight C ISO14443A 192 byte No Read/Write
ICODE SLIX ISO15693 1024 bit Yes Read/Write
Available 860-960MHz Chip
Alien H3 ISO18000-6C 512 bit Yes Read/Write
Other chips are also available.

NTAG are registered trademarks of NXP B.V. and are used under license.

ICODE are registered trademarks of NXP B.V. and are used under license.

MIFARE and MIFARE Classic are trademarks of NXP B.V.

MIFARE and MIFARE Ultralight have registered trademarks of NXP B.V. and are used under license.

MIFARE and MIFARE Plus have registered trademarks of NXP B.V. andare used under license.

5\ Video of NFC Tag Production Process

Play Video

XINYETONG has its factory, more than 10 years of experience in RFID production. We have professional production equipment and masterful operators to ensure the high quality of our RFID products.

PCB NTAG 213 NFC Tag is suited for the process of global Instrumentation, to provide more convenience for life. We can provide customized sizes to choose from for you. No matter what the problem is, we all give you practical suggestions during the whole contact.

If you want to know more information about us and our products, feel free to contact us!
